USA 35079 - Sailor Bandido

2001 Quest 33



Designer - Rodger Martin Yacht Design

Builder - Holby Marine Company



LOA 32' 6"                     SAIL AREA: main & 150 jib 694 SF

LWL 29' 4"                     SAIL AREA: triangles 512 SF

MAX BEAM 11' 4"          DOWNWIND SAIL AREA 1,580 SF

DRAFT 8.0 ft.

DSPL 8,000 lbs.            BALLAST, BULB & FIN 1,950 lbs.

SPRIT LENGTH 6.3 ft.



DISP/LENGTH 106

SA/DISP 33.6

I 41.0 ft.

J 10.7 ft.

P 40.0 ft.

E 15.0 ft.

The Boats

Sailor Bandido 87 at the start of the 1998 Chicago to Mackinac Race

USA 15330 - Mabilis

2007 - Lightning



Designer—Sparkman & Stephens

Builder—Nickels Boat Works



LOA 19’ 0"                      SAIL AREA: Main & 100% Jib 172 SF

LWL 15’ 3”                      DOWNWIND SAIL AREA 350 SF

MAX BEAM 6' 6"

DRAFT 4.95 ft.

DSPL 700 lbs.               BALLAST, FIN 130 lbs.



DISP/LENGTH 88

SA/DISP 34.96

I 20.0 ft.

J 6.91 ft.

P 24.00 ft.

E 10.00 ft.





USA 2606 - Hijo Del Bandido

2014 - Donovan GP26



Designer—Jim Donovan

Builder—Mag Marin Composites/W Raceboats



LOA 25.92’                     SAIL AREA: Main & 100% Jib 226 SF

LWL 25.92’                     DOWNWIND SAIL AREA 887 SF

MAX BEAM 8.37'

DRAFT 6.23 ft.

DSPL 2,205 lbs.               BALLAST, FIN 1,102 lbs.

SPRIT LENGTH 15.75 Ft



DISP/LENGTH 56.5

SA/DISP 33.1

I 30.35 ft.

J 9.51 ft.

P 32.48 ft.

E 12.63 ft.
